DRF-12V120W1GTA
12Vdc, 10A, DIN Rail Power Supply, Spring Clamp Terminal, PFC, Conformal Coated, AC Input: 90-264VacManufacturer: Delta
View Data Sheet
In Stock: 24 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage:
12Vdc
Output Max Current:
10 Amps
Max Power:
120 Watts
Known Country of Origin:
China
Features
DIN rail power supply
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1, UL 61010-1
SEMI F47
SELV
DC OK signal
Built-in PFC
No load power consumption <0.5W max
LED indicator for DC OK
Adjustable output voltage
Constant current mode operation
Leakage current <0.5mA
Conformal coating on PCBAs to protect against common dust and pollutants
Operation up to 5000m altitude
Protections: overload / overvoltage / over temperature / short circuit
Delta 2 year warranty
