DRF-12V240W1GBA
12Vdc 20A Power Supply DIN Rail w-Conformal Coating 12 Volts 20 AmpsManufacturer: Delta
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage:
12Vdc
Output Max Current:
20 Amps
Max Power:
240 Watts
Known Country of Origin:
China
Features
DIN rail power supply
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1, UL 61010-1
SEMI F47
Ultra-slim design
DC OK signal
No load power consumption <0.5mA
LED indicator for DC OK
Adjustable output voltage
Constant Current mode operation
Conformal coating on PCBAs to protect against common dust and pollutants
Leakage current <0.5mA
Operation up to 5000m altitude
Protections: overload / overvoltage / over temperature / short circuit
DELTA Power 2 year warranty
