ELG-75-24
24Vdc 3.15A 24V LED Power Supply, IP67 Operates: CV or CC ModeManufacturer: MEAN WELL
View Data Sheet
In Stock: 2 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
100~305Vac
Output Voltage (CV mode):
24Vdc
Output Max Current (CV mode):
3.15 Amps
Output Current (CC mode):
3.15 Amps
Constant Current Operating Range:
12~24Vdc
Max Power:
76 Watts
Known Country of Origin:
China
Features
AC input range: 100~305Vac
Operating case temperature: -40~+85°C
UL8750 safety approved
Type HL for use in Class I, Division 2 hazardous (Classified) location
No load power consumption <0.5W
Built-in active PFC function
IP67 durable metal enclosure
Protections: over current / short circuit / over voltage / over temperature
Applications: LED street lighting, LED high bay lighting and other indoor/outdoor lighting
MEAN WELL 5 year warranty
