Power Worth Searching For
TPI 100-128A-J
24Vdc 4.17A, 28 Volt Power Supply 2x3 Open Frame PFCManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
24Vdc
Output Max Current:
4.17 Amps
Max Power:
100 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPI 100-128A-J 2x3 class II open frame power supply
AC input range: 85~264Vac
Operating temperature: -40~+80°C
Safety approvals: UL 60950-1, IEC/EN 60950-1
Built-in active PFC
I/O reinforced isolation 3000Vdc
Adjustable output voltage
High efficiency
Operating up to 5000m altitude
No load power consumption <0.3W
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
