Power Worth Searching For
JTL3024T0515
DC/DC ConverterManufacturer: XP Power
View Data Sheet
In Stock: 1 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$84.15
5
$81.63
10
$79.10
25
$75.74
100
$70.69
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
4 Amps
Output Voltage #2:
15Vdc
Output #2 Max Current:
0.33 Amps
Output Voltage #3:
-15Vdc
Output #3 Max Current:
-0.33 Amps
Max Power:
30 Watts
Known Country of Origin:
Taiwan
Features
XP Power JTL3024T0515 2x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+75°C
I/O isolation: 1600Vdc
No minimum load required (single & dual output models)
Remote On/Off
Adjustable output voltage (single output models only)
Fully regulated output
Protections: short circuit / overload / overvoltage / over temperature / undervoltage-lockout
XP Power 3 year warranty
