HLG-240H-36
36Vdc 6.7A LED Driver, IP67, PFC Harsh Environment, Metal Case 36V 6.7AManufacturer: MEAN WELL
View Data Sheet
In Stock: 24 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~305Vac
Output Voltage (CV mode):
36Vdc
Output Max Current (CV mode):
6.7 Amps
Output Current (CC mode):
6.7 Amps
Constant Current Operating Range:
18~36Vdc
Max Power:
241 Watts
Known Country of Origin:
Taiwan
Features
Full range AC input: 90~305Vac
Operating case temperature: -40~+90°C
UL 62368-1, UL1012 approval
UL8750 type HL LED power supply
Built-in active PFC
Durable aluminum enclosure with screw terminal connections for input & output
High efficiency
Output voltage and constant current level can be adjusted through internal potentiometers
Protections: short circuit / over current / over voltage / over temperature
MEAN WELL 7 year warranty
