TPI 150-148A-J
48Vdc 3.13A, 48 Volt PFC Power Supply Open FrameManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
3.13 Amps
Max Power:
150 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPI 150-148A-J 2x4 open frame power supply
Universal AC input range: 85~264Vac
Operating temperature: -40~+80°C
ITE safety approval: UL60950-1, IEC/EN 60950-1
No load power consumption <0.3W
Class II
Built-in active PFC
I/O reinforced isolation 3000Vdc
Adjustable output voltage
High efficiency
Operating up to 5000m altitude
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
