PDAM120-18A
Medical Power Supply Open Frame, 2x3 48V 2.5A 120WManufacturer: TT Electronics
View Data Sheet
In Stock: 2 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage:
48Vdc
Output Max Current:
2.5 Amps
Max Power:
120 Watts
Known Country of Origin:
Taiwan
Features
Power Partners PDAM120-18A compact 2x3 inch open frame AC/DC medical power supply
AC input range: 90~264Vac
Operating temperature range: -30~+70°C (with derating)
Industrial safety certification: EN 62368-1, UL 62368-1
Medical safety certification: UL/IEC/EN 60601-1 3rd Edition
Suitable for BF application
2xMOPP
Low leakage current <100µA
Built-in active PFC function
High efficiency
High power density: 15.27W per cubic inch
No load power consumption <300mW
Class I or Class II configuration
Protections: short circuit / over temperature / over current / over voltage
TT Electronics 1 year warranty
