Power Worth Searching For
TPP 450-148B-M
48Vdc 9.4A, 48 Volt Medical Power Supply Enclosed with Fan, Class II 48 Volts 9.4 AmpsManufacturer: TRACO Power
View Data Sheet
In Stock: 1 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$250.30
5
$223.58
10
$222.14
25
$220.72
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
9.4 Amps
Max Power:
451 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPP 450-148B-M high power density enclosed medical & industrial power supply with fan
AC input range: 85~264Vac
Operating temperature range: -40~+80°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1
2xMOPP
Suitable for type BF applications
EMC emission compliant to IEC 60601-1-2 4th edition
Class I and class II prepared
Low leakage current ≤100µA
No load power consumption ≤0.8 Watts
Built-in cooling fan with variable speed control
Built-in 5V/2A standby output
Remote On/Off
Remote sense function
DC OK signal
Power good signal
Adjustable output voltage
Built-in PFC, Operation up to 5000m altitude
TPP 450-148B-M
48Vdc 9.4A, 48 Volt Medical Power Supply Enclosed with Fan, Class II 48 Volts 9.4 AmpsManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
9.4 Amps
Max Power:
451 Watts
Known Country of Origin:
Taiwan
Features
In Stock: 1 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$250.30
5
$223.58
10
$222.14
25
$220.72
REQUEST a QUOTE for higher qty discounts
