REL-150-4006-CHCO
Quad Output Power Supply , Chassis & Cover , ITE & Medical CertificationManufacturer: IPD
View Data Sheet
In Stock: 1 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$205.98
3
$199.84
10
$196.90
25
$186.99
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage #1:
5Vdc
Output #1 Max Current:
15 Amps
Output Voltage #2:
24Vdc
Output #2 Max Current:
3 Amps
Output Voltage #3:
12Vdc
Output #3 Max Current:
2 Amps
Output Voltage #4:
-12Vdc
Output #4 Max Current:
2 Amps
Max Power:
150 Watts
Known Country of Origin:
USA
Features
IPD REL-150-4006-CHCO enclosed medical power supply with chassis & cover
AC input range: 85~264Vac
Operating temperature: 0~+70°C
UL60950-1 ITE and AAMI/ANSI ES 60601-1 medical certifications
PFC
Small compact size, dimensions: 3.96″x6.25″x1.48″
Available in open frame and chassis
Protections: over voltage / over power
Integrated Power Designs 2 year warranty
