TPP 150-128
28Vdc 5.36A, 28 Volt PFC Power Supply Medical & ITE Safety Approvals 2.44x4"Manufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$133.61
5
$115.54
10
$114.80
25
$114.06
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage:
28Vdc
Output Max Current:
5.36 Amps
Max Power:
150 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPP 150-128 high power density enclosed 150W power supply 2.44x4
Universal AC input range: 85~264Vac
Operating temperature: -25~+80°C
Medical afety approval: AAMI/ANSI ES 60601-1 and IEC/EN 60601-1 3rd edition
2xMOPP
Suitable for BF application
ITE safety approval: UL 60950-1
Class I & class II protection
Enclosed with fan
Built-in active PFC
Low leakage current <100µA
I/O reinforced isolation 4000Vdc
Adjustable output voltage
High efficiency
Operating up to 5000m altitude
Protections: short circuit / over load / over voltage
TRACO Power 5 year warranty
