TPP 40-105
5Vdc 8A, 5 Volt Medical Power Supply PFC, 2xMOPP EnclosedManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
5Vdc
Output Max Current:
8 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPP 40-105 miniature power supply with class I & class II protection
Universal AC input range: 85~264Vac
Operating temperature: -40~+80°C
Medical safety approval: IEC/EN/ES 60601-1 3rd edition
2xMOPP
ITE safety approval: UL60950-1
Risk management process according to ISO 14971 including risk management file
Acceptance criteria for electronic assemblies according to IPC-A-610 Level 3
Built-in active PFC
Low leakage current <75µA
Operating up to 5000m altitude
No load power consumption <0.15W
Protections: short circuit / over voltage/ over load
TRACO Power 3 years warranty
