TPP 40-136E-J
36Vdc 1.12A, 36 Volt 1.12A Power Supply Medical & ITE Safety Certs Encapsulated, JST ConnectorsManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
36Vdc
Output Max Current:
1.12 Amps
Max Power:
40 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPP 40-136E-J chassis mount medical & industrial power supply
AC input range: 85~264Vac
Operating temperature: -40~+85°C
Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1
2xMOPP
Suitable for BF application
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
MIL-STD-810F
Adjustable output voltage
Withstands 5G vibration
High efficiency
Class I and class II prepared
Low leakage current ≤100µA
No load power consumption ≤0.11W
Operation up to 5000m altitude
Protections: short circuit / overvoltage
TRACO Power 5 year warranty
