TPP 65-105
5Vdc 10A, 5 Volt Medical Power Supply PFC, 2xMOPP EnclosedManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
5Vdc
Output Max Current:
10 Amps
Max Power:
50 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPP 65-105 enclosed high power density power supply
Universal AC input range: 85~264Vac
Operating temperature: -40~+85°C
Medical safety approval: AAMI/ANSI ES 60601-1:2005(R) & IEC/EN 60601-1 3rd edition
2xMOPP
Suitable for BF application
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Class II
Built-in active PFC
Low leakage current <75µA
High efficiency
Adjustable output voltage
Operating up to 5000m altitude
No load power consumption <0.3W
Protections: short circuit / over voltage / over load
TRACO Power 5 year warranty
