TPP 65-3512
24V, 5V, 12V, Medical Power Supply PFC, 2xMOPP Enclosed, Triple OutputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
Factory Stock: 29 i If factory stock is available, we can typically ship that additional stock from the factory to you within two weeks. Contact us to confirm timing for your quantity.
Quantity
Unit Price
1
$119.26
5
$103.23
10
$102.57
25
$101.90
Click for Quote for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage #1:
24Vdc
Output #1 Max Current:
2.71 Amps
Output Voltage #2:
5Vdc
Output #2 Max Current:
8 Amps
Output Voltage #3:
12Vdc
Output #3 Max Current:
0.6 Amps
Max Power:
65 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TPP 65-3512 enclosed high power density power supply
Universal AC input range: 85~264Vac
Operating temperature: -40~+85°C
Medical safety approval: AAMI/ANSI ES 60601-1:2005(R) & IEC/EN 60601-1 3rd edition
2xMOPP
Suitable for BF application
Class II
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Built-in active PFC
Low leakage current <75µA
High efficiency
Adjustable output voltage
Operating up to 5000m altitude
No load power consumption <0.3W
Protections: short circuit / over voltage / over load
TRACO Power 5 year warranty
