HVG-100-20B
I/P 180~480Vac O/P 20V 4.8A Dimmable LED Driver, IP67 Wide Input Range: 180~528Vac Durable Metal CaseManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
180~528Vac
Constant Current:
4800mA
Constant Current Operating Range:
10~20Vdc
Max Power:
96 Watts
Known Country of Origin:
China
Features
Wide range AC input: 180~528Vac
Working case temperature: -40~+90°C
Safety approval: UL8750
Type HL for use in Class I, Division 2 hazardous (Classified) location
Class 2
Constant current level adjustable through output dimming leads with 0~10VDC or 10V PWM sign or resistance dimmer
High efficiency
Built-in active PFC
Durable metal enclosure
Protections: short circuit, over temperature, over current, over voltage
Applications: LED street lighting, LED high bay lighting, LED office lighting and other indoor/outdoor lighting
MEAN WELL 5 year warranty
