THN 10-7213UIR
15Vdc 0.67A, Ultra-Wide 12:1 Input 10W DC/DC Converter in 1x1" PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
14~160Vdc
Output Voltage:
15Vdc
Output Max Current:
0.67 Amps
Max Power:
10 Watts
Known Country of Origin:
Taiwan
Features
1x1 package DC/DC converter
Ultra wide 12:1 input voltage range
Operating temperature: -40~+80°C (up to +85°C with optional heat-sink)
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
MIL-STD-810F
I/O isolation 3000Vdc
Remote On/Off
Output voltage adjustment
Under-voltage lock out circuit
Operation up to 5000m altitude
Protections: short circuit / overvoltage / over temperature
TRACO Power 3 year warranty
TRACO Power 3 year warranty
