Power Worth Searching For
THN 30-4823WIR
Dual O/P, Railway DC/DC Converter 1x1 Package 4:1 InputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
1 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-1 Amps
Max Power:
30 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THN 30-4823WIR 1x1 inches railway DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+65°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
MIL-STD-810F
Input filter meets EN 55032 class A
I/O isolation 3000Vdc
Output voltage trim function
Remote On/Off
Adjustable output voltage
Under-voltage lock out circuit
Operation up to 5000m altitude
Protections: short circuit / over temperature / overvoltage
TRACO Power 3 year warranty
