TEP 200-4813WIRCMF
15Vdc 14A, DC/DC Converter, Railway Screw Terminal, EMI Filter Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$522.99
5
$473.46
10
$437.43
25
$405.26
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
15Vdc
Output Max Current:
14 Amps
Max Power:
210 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEP 200-4813WIRCMF rugged DC/DC converter with screw terminals and input filter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+75°C
EN 50155 approval for demanding applications such as railway and transportation
EMI filter to meet EN 55022 class A
Adjustable output voltage +10/-20%
High efficiency
Soft start
Sense line
Easy chassis mount with screw terminal block
Remote On/Off input
Reverse input voltage protection
Under voltage lock-out circuit
Protections: short circuit / over temperature / over voltage
TRACO Power 3 year warranty
