Power Worth Searching For
TEP 75-4816WI-CMF
28Vdc 2.7A, DC/DC Converter Terminal, EMI Filter, Railway Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$274.48
5
$248.94
10
$229.59
25
$212.69
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
28Vdc
Output Max Current:
2.7 Amps
Max Power:
75.6 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TEP 075-4816WI-CMF high performance compact & rugged package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+75°C
EN 50155 approval for demanding applications such as railway and transportation
Chassis mount with screw terminal block and input filter to meet EN 55022 class A
Input protection filter
Remote On/Off
Remote sense
Reverse input voltage protection
Under voltage lock-out circuit
Protections: short circuit / over temperature / over voltage
TRACO Power 3 year warranty
