DRC-40B
27.6Vdc 0.95A +27.6Vdc 0.5A, 27.6V DIN Rail Power Supply Battery Charger Output UPS FunctionManufacturer: MEAN WELL
View Data Sheet
In Stock: 172 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage #1:
27.6Vdc
Output #1 Max Current:
1.45 Amps
Output Voltage #2:
27.6Vdc
Output #2 Max Current:
0.5 Amps
Max Power:
40 Watts
Known Country of Origin:
China
Features
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
High efficiency
Fan-less design, cooling by free air convection
Alarm signal for AC OK and battery low
Battery low cut off / battery reverse polarity protection (by fuse)
Pass LPS
LED indicator for power on
Installed on DIN rail TS35 / 7.5 or 15
Protections: short circuit / overload / over voltage
MEAN WELL 3 year warranty
