TIB 080-124EX
24V 3.4A, 24 Volt DIN Rail Power Supply UL508 Industrial Control ATEX CertificationManufacturer: TRACO Power
View Data Sheet
In Stock: 6 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
24Vdc
Output Max Current:
3.4 Amps
Output Peak Current:
5.1 Amps
Max Power:
80 Watts
Known Country of Origin:
China
Features
TRACO Power TIB 080-124EX slim profile DIN rail power supply with ATEX certification
AC input range: 85~264Vac
Operating temperature range: -40~+70°C
Safety approvals: UL/IEC/EN 60950-1, UL 508, EN 60079
Class I, division 2 for hazardous location
Railway applications shock and vibration according to EN 61373
Adjustable output voltage
Built-in active PFC
Alternative side-mounting for flat panels
Back power immunity
Peak current up to 150% for 4 seconds
DC OK LED indicator
Standard protections: over load / short circuit
TRACO Power 5 year warranty
TIB 080-124EX
24V 3.4A, 24 Volt DIN Rail Power Supply UL508 Industrial Control ATEX CertificationManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
24Vdc
Output Max Current:
3.4 Amps
Output Peak Current:
5.1 Amps
Max Power:
80 Watts
Known Country of Origin:
China
Features
