MDD03G-15
3W; I/P: 18-75Vin; +/-15Vout @100mA Medical DC/DC Converter DIP Dual OutputManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$15.49
10
$15.28
25
$15.09
50
$14.89
100
$14.52
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.1 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.1 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
Ultra-Wide 4:1 input range
Operating temperature range: -40~+90°C
Medical safety certification: IEC 60601-1 3rd edition
2xMOPP
I/O isolation: 6000Vdc
I/O isolation: 4200Vac
Fully regulated output
Low patient leakage current <5µA
Protections: short circuit (continuous) / overload
MEAN WELL 3 year warranty
