Power Worth Searching For
TDN 1-1223WI
Dual O/P, DC/DC Converter DIP-8 Package Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$22.46
10
$19.35
25
$19.09
100
$17.07
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
4.5~18Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.035 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.035 Amps
Max Power:
1 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TDN 1-1223WI DIP-8 package DC/DC converter
Ultra wide: 4:1 input range
Operating temperature: -40~+90°C
I/O isolation 1500Vdc
Ultra compact size: 13.2 x 9.1 x 10.2mm
Fully regulated output
Remote On/Off
Short-circuit protection
TRACO Power 3 year warranty
TDN 1-1223WI
Dual O/P, DC/DC Converter DIP-8 Package Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
4.5~18Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.035 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.035 Amps
Max Power:
1 Watts
Known Country of Origin:
Taiwan
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$22.46
10
$19.35
25
$19.09
100
$17.07
REQUEST a QUOTE for higher qty discounts
