THD 10-1222N
Dual O/P, DC-DC Converter DIP-24 Package 2:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.416 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.416 Amps
Max Power:
10 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THD 10-1222N DIP-24 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+85°C
Internal EMI-filter meets EN55022, class A without external components
I/O isolation 1500Vdc
High efficiency
No minimum load required
Protections: over load / short circuit
TRACO Power 3 year warranty
