THD 12-4811WI
5.1Vdc 2.4A, DC-DC Converter DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
In Stock: 3 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
5.1Vdc
Output Max Current:
2.4 Amps
Max Power:
12.24 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THD 12-4811WI DIP-24 package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
Safety approvals: UL/EN/IEC 60950-1
Input filter to meet EN 55022, class A
I/O isolation 1500Vdc
Under voltage lock-out circuit
Shielded metal case with insulated baseplate
Remote On/Off
Protections: over load / over voltage / short circuit
TRACO Power 3 year warranty
