THD 15-2423WIN
Dual O/P, DC-DC Converter DIP-24 Package Wide 4:1 Input Voltage RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~36Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.5 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
0.5 Amps
Max Power:
15 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THD 15-2423WIN DIP-24 package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
Safety approvals: UL/cUL 60950-1 & IEC/EN 60950-1
Internal EMI-filter meets EN55022, class A without external components
I/O isolation 1500Vdc
No minimum load required
Remote On/Off
Shielded metal case with isolated baseplate
Protections: short circuit / over voltage
TRACO Power 3 year warranty
