THL 30-4810WI
3.3Vdc 7A, Regulated DC/DC Converter 1x1 Metal Package 4:1 Input, Remote On/Off, TrimManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
7 Amps
Max Power:
30 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THL 30-4810WI 1x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+80°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
I/O isolation: 1500Vac
Built-in remote On/Off
Trim function
No minimum load required
Operation up to 6000m altitude
Under voltage lock-out circuit
Protections: short circuit / overvoltage / overload
Optional heastsink
TRACO Power 3 year warranty
