TMF 30105
5Vdc 5A, 5 Volt Medical Power Supply PCB Mounting 2xMOPPManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage:
5Vdc
Output Max Current:
5 Amps
Max Power:
30 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power TMF 30105 fully encapsulated medical AC/DC power supply for PCB mount
Universal AC input range: 90~264Vac
Operating temperature: -25~+70°C
Medical safety approvals: ANSI/AAMI IEC/EN/ES 60601-1 3rd edition for 2xMOPP
Suitable for BF application
Risk management process according to ISO 14971 including risk management file
Acceptance criteria for electronic assemblies according to IPC-A-610 Level 3
Low leakage current <100µA rated for BF applications
Protection class ll prepared
Protections: short circuit / overload / over voltage
TRACO Power 5 year warranty
