PAA50-13
15V PCB Mount Power Supply Encapsulated 15 Volts 3.333 AmpsManufacturer: TT Electronics
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~305Vac
Output Voltage:
15Vdc
Output Max Current:
3.333 Amps
Max Power:
50 Watts
Known Country of Origin:
Taiwan
Features
Power Partners PAA50-13 encapsulated AC/DC power supply
AC input range: 90~305Vac
Operating temperature range: -40~+70°C
Industrial safety certification: IEC/EN 60950-1, IEC/EN 62368-1, UL 62368-1
Class II isolation
EMC compliant without external components
Class B conducted & radiated emissions
I/O isolation 4000Vac
No load power consumption <0.1 watt
Protections: overvoltage / overload / short circuit
TT Electronics 1 year warranty
