Power Worth Searching For
PAAM100-14
24V PCB Mount Power Supply Medical & ITE Certifications 24 Volts 4.2 AmpsManufacturer: TT Electronics
View Data Sheet
In Stock: 5 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage:
24Vdc
Output Max Current:
4.2 Amps
Max Power:
100 Watts
Known Country of Origin:
Taiwan
Features
Power Partners PAAM100-14 encapsulated medical and ITE AC/DC power supply
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
Medical safety certification: EN 60601-1-2 4th edition
2xMOPP
Suitable for BF applications
Industrial safety certification: IEC/EN 62368-1, UL 62368-1, IEC/EN 60950-1, UL 60950-1
Built-in PFC
Built-in remote On/Off
Adjustable output voltage
Class I and class II prepared
Low leakage current <0.1mA
Class B conducted & radiated emissions
I/O isolation 4000Vac
No load power consumption <0.5 watt
Operation up to 5000m altitude
Protections: overvoltage / overload / short circuit / over temperature
TT Electronics 1 year warranty
