ECE20US03
3.3Vdc 4.55A, 3.3V PCB Mount Power Supply, Encapsulated, 3.3 Volts 4.55 AmpsManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$74.13
5
$71.90
10
$69.68
25
$66.71
100
$62.26
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage:
3.3Vdc
Output Max Current:
4.55 Amps
Output Peak Current:
5.85 Amps
Max Power:
15 Watts
Known Country of Origin:
China
Features
XP Power ECE20US03 encapsulated AC/DC power supply
AC input range: 85~264Vac
Operating temperature range: -25~+70°C
Industrial safety certification: IEC 60950-1, IEC/EN 62368-1, UL 62368-1
Class II
Peak power
No minimum load required
No load power consumption <0.3 watts
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
ECE20US03
3.3Vdc 4.55A, 3.3V PCB Mount Power Supply, Encapsulated, 3.3 Volts 4.55 AmpsManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
3.3Vdc
Output Max Current:
4.55 Amps
Output Peak Current:
5.85 Amps
Max Power:
15 Watts
Known Country of Origin:
China
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$74.13
5
$71.90
10
$69.68
25
$66.71
100
$62.26
REQUEST a QUOTE for higher qty discounts
