ECL10US09-E
9Vdc 1.1A, 9V On Board Power Supply, Encapsulated, Peak Current, 9 Volts 1.1 AmpsManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$52.95
5
$51.37
10
$49.78
25
$47.66
100
$44.49
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage:
9Vdc
Output Max Current:
1.1 Amps
Output Peak Current:
1.43 Amps
Max Power:
10 Watts
Known Country of Origin:
China
Features
XP Power ECL10US09-E encapsulated power supply
AC input range: 85~264Vac
Operating temperature range: -20~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Protection Class II
Peak power
Reinforced I/O isolation 3000Vac
No load power consumption ≤0.3 watts
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
ECL10US09-E
9Vdc 1.1A, 9V On Board Power Supply, Encapsulated, Peak Current, 9 Volts 1.1 AmpsManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
9Vdc
Output Max Current:
1.1 Amps
Output Peak Current:
1.43 Amps
Max Power:
10 Watts
Known Country of Origin:
China
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$52.95
5
$51.37
10
$49.78
25
$47.66
100
$44.49
REQUEST a QUOTE for higher qty discounts
