Power Worth Searching For
ECL30UT03-E
5V, 15V, -15V, Triple Output Power Supply, Encapsulated, PCB MountManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$110.50
5
$107.18
10
$103.87
25
$99.45
100
$92.83
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage #1:
5Vdc
Output #1 Max Current:
3 Amps
Output Voltage #2:
15Vdc
Output #2 Max Current:
0.5 Amps
Output Voltage #3:
-15Vdc
Output #3 Max Current:
0.5 Amps
Max Power:
30 Watts
Known Country of Origin:
China
Features
XP Power ECL30UT03-E encapsulated PCB mount power supply
AC input range: 85~264Vac
Operating temperature range: -20~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Triple output models
Class II
Peak power up to 130% for <30 sec
Reinforced I/O isolation 3000Vac
No load power consumption <0.3W
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
ECL30UT03-E
5V, 15V, -15V, Triple Output Power Supply, Encapsulated, PCB MountManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage #1:
5Vdc
Output #1 Max Current:
3 Amps
Output Voltage #2:
15Vdc
Output #2 Max Current:
0.5 Amps
Output Voltage #3:
-15Vdc
Output #3 Max Current:
0.5 Amps
Max Power:
30 Watts
Known Country of Origin:
China
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$110.50
5
$107.18
10
$103.87
25
$99.45
100
$92.83
REQUEST a QUOTE for higher qty discounts
