EML15US36-E
36Vdc 0.42A, 36V Encapsulated Power Supply, PCB Mount, Class II, 36 Volts 0.42 AmpsManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$62.74
5
$60.86
10
$58.97
25
$56.47
100
$52.70
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage:
36Vdc
Output Max Current:
0.42 Amps
Output Peak Current:
0.54 Amps
Max Power:
15 Watts
Known Country of Origin:
China
Features
XP Power EML15US36-E encapsulated medical power supply
AC input range: 85~264Vac
Operating temperature range: -20~+70°C
Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1
2xMOPP
Protection Class II
Peak power
Reinforced I/O isolation 4000Vac
No load power consumption ≤0.3 watts
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
