MDD02M-05N
2 W; I/P: 12VDC; O/P: +/- 5V@+/-200mA; SIP Medical DC/DC Converter, SIP-7, 2xMOOP, Dual OutputManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$6.25
10
$6.17
25
$6.09
50
$6.01
100
$5.86
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
10.8~13.2Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.2 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-0.2 Amps
Max Power:
2 Watts
Known Country of Origin:
China
Features
Medical SIP-7 DC/DC converter
Input voltage range: 10.8~13.2Vdc
Operating temperature range: -40~+95°C
I/O isolation: 6,000Vdc
Industrial safety certification: IEC 62368-1, UL 62368-1
Medical safety certification: IEC 60601-1
2xMOOP
Low leakage current <2µA
Protections: short circuit (continuous)
MEAN WELL 3 year warranty
