Power Worth Searching For
RSDW10H-05
10W I/P: 43-160VDC; O/P: 5V@2000mA, 5Vdc DC/DC Converter Ultra Wide Input Voltage Range DIP-24, Railway, 10 WattsManufacturer: MEAN WELL
View Data Sheet
In Stock: 27 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$24.70
10
$24.38
25
$24.06
50
$23.75
100
$23.16
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
43~160Vdc
Output Voltage:
5Vdc
Output Max Current:
2 Amps
Max Power:
10 Watts
Known Country of Origin:
China
Features
Ultra wide input voltage range
Operating temperature range: -40~+85°C
Complies to EN 50155 railway standard
3000Vdc I/O isolation
Single output
No minimum load required
Remote On/Off
Protections: continuous short circuit / over load / over voltage / input under voltage
MEAN WELL 3 year warranty
RSDW10H-05
10W I/P: 43-160VDC; O/P: 5V@2000mA, 5Vdc DC/DC Converter Ultra Wide Input Voltage Range DIP-24, Railway, 10 WattsManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
43~160Vdc
Output Voltage:
5Vdc
Output Max Current:
2 Amps
Max Power:
10 Watts
Known Country of Origin:
China
Features
In Stock: 27 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$24.70
10
$24.38
25
$24.06
50
$23.75
100
$23.16
REQUEST a QUOTE for higher qty discounts
