HLG-185H-20
20Vdc 9.3A LED Driver, IP67, PFC Harsh Environment, Metal Case 20V 9.3AManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~305Vac
Output Voltage (CV mode):
20Vdc
Output Max Current (CV mode):
9.3 Amps
Output Current (CC mode):
9.3 Amps
Constant Current Operating Range:
10~20Vdc
Max Power:
186 Watts
Known Country of Origin:
Philippines
Features
Full range AC input: 90~305Vac
Operating case temperature: -40~+90°C
UL8750 LED power supply
Meet 4kV surge immunity level (IEC61000-4-5)
Built-in active PFC, THD <20%
IP67 durable aluminium enclosure
High efficiency
Long life
Protections: short circuit / over current / over voltage / over temperature
Applications: LED electric display, lighting, LED street lighting and indoor/outdoor lighting
MEAN WELL 7 year warranty
