Power Worth Searching For
HLG-600H-15AB
15Vdc 36A 15Vdc Dimmable LED Driver Adjustable Voltage,Current 3 in 1 Dimming, IP65, CC or CVManufacturer: MEAN WELL
View Data Sheet
In Stock: 4 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$242.54
5
$231.04
10
$220.80
20
$214.48
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
90~305Vac
Output Voltage (CV mode):
15Vdc
Output Max Current (CV mode):
36 Amps
Output Current (CC mode):
36 Amps
Constant Current Operating Range:
7.5~15Vdc
Max Power:
540 Watts
Known Country of Origin:
Taiwan
Features
AC input range: 90~305Vac
Operating case temperature: -40~+90°C
Safety approvals: UL60950-1, UL8750
Type HL for use in Class I, Division 2 hazardous (Classified) location
Meet 4kV surge immunity level (IEC 61000-4-5)
5Vdc @ 0.5A stand-by power
Remote On/Off
Built-in PFC
High efficiency
IP65 durable aluminium enclosure
Withstands 5G vibration
Output voltage and constant current level can be adjusted through internal potentiometers
3 in 1 dimming function: 0-10Vdc dimmer (dim to off), 10V PWM dimmer, or resistance dimmer
Protections: short circuit / over current / over voltage / over temperature
MEAN WELL 7 year warranty
HLG-600H-15AB
15Vdc 36A 15Vdc Dimmable LED Driver Adjustable Voltage,Current 3 in 1 Dimming, IP65, CC or CVManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
90~305Vac
Output Voltage (CV mode):
15Vdc
Output Max Current (CV mode):
36 Amps
Output Current (CC mode):
36 Amps
Constant Current Operating Range:
7.5~15Vdc
Max Power:
540 Watts
Known Country of Origin:
Taiwan
Features
In Stock: 4 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$242.54
5
$231.04
10
$220.80
20
$214.48
REQUEST a QUOTE for higher qty discounts
