PCD-25-1400A
I/P 90~135Vac O/P +12~18V 1400mA, LED Driver, 1400mA Dimmable with TRIAC DimmerManufacturer: MEAN WELL
View Data Sheet
In Stock: 6 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~135Vac
Constant Current:
1400mA
Constant Current Operating Range:
12~18Vdc
Max Power:
25 Watts
Known Country of Origin:
China
Features
AC input: 90~135Vac
Operating temperature: -30~+60°C
Class 2 UL8750, LPS LED driver
Class II AC input (two wires-no FG connection)
AC phase-cut method using electronic type dimmers: leading edge and trailing edge TRIAC
Built-in active PFC
IP42, UL94V-0 insulated plastic case, small compact size
Protections: short circuit / over temperature
MEAN WELL 3 year warranty
