PCD-40-350B
I/P 180~295Vac O/P +70~108V 350mA, LED Driver, 350mA Dimmable with TRIAC DimmerManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
180~295Vac
Constant Current:
350mA
Constant Current Operating Range:
70~108Vdc
Max Power:
37 Watts
Known Country of Origin:
China
Features
AC input: 180~295Vac
Operating temperature: -30~+50°C
Class II AC input (two wires-no FG connection)
AC phase-cut method using electronic type dimmers: leading edge and trailing edge TRIAC
Built-in active PFC
IP42, UL94V-0 insulated plastic case, small compact size
Protections: short circuit / over temperature
MEAN WELL 3 year warranty
