Power Worth Searching For
PLN-100-27
27V3.55A 27Vdc LED Power Supply IP64, Class 2, PFC Operates: CV or CC ModeManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~295Vac
Output Voltage (CV mode):
27Vdc
Output Max Current (CV mode):
3.55 Amps
Output Current (CC mode):
3.55 Amps
Constant Current Operating Range:
20.25~27Vdc
Max Power:
95 Watts
Known Country of Origin:
China
Features
AC input: 90~295Vac
Operating temperature: -30~+50°C
Built-in active PFC > 0.9 at operation of 75% of rated load or higher
High efficiency
Fully isolated plastic case with IP64 rating
Class 2 power unit, Pass LPS
Protections: short circuit / over current / over voltage / over temperature
MEAN WELL 2 year warranty
PLN-100-27
27V3.55A 27Vdc LED Power Supply IP64, Class 2, PFC Operates: CV or CC ModeManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
90~295Vac
Output Voltage (CV mode):
27Vdc
Output Max Current (CV mode):
3.55 Amps
Output Current (CC mode):
3.55 Amps
Constant Current Operating Range:
20.25~27Vdc
Max Power:
95 Watts
Known Country of Origin:
China
Features
