MPM-15-15
15Vdc 1A Medical Power Supply PCB Mount, EncapsulatedManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
80~264Vac
Output Voltage:
15Vdc
Output Max Current:
1 Amps
Output Peak Current:
1.1 Amps
Max Power:
15 Watts
Known Country of Origin:
China
Features
AC input range: 80~264Vac
Operating temperature: -40~+85°C (with derating)
Medical safety approvals: UL ANSI/AAMI ES 60601-1 & IEC/EN 60601-1
2xMOPP
Extremely low leakage current <80µA
Suitable for BF applications
Peak current capability
Low no load power consumption <0.075W
Class II double insulation (No FG)
Compact size: 2.06x1.07 inches
Protections: short circuit /over load / over voltage / over temperature
MEAN WELL 3 year warranty
