MPM-90-15
15Vdc 5.67A Medical Power Supply PCB Mount, EncapsulatedManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
80~264Vac
Output Voltage:
15Vdc
Output Max Current:
5.67 Amps
Output Peak Current:
6.23 Amps
Max Power:
85 Watts
Known Country of Origin:
China
Features
AC input range: 80~264Vac
Operating temperature range: -30~+80°C
Medical safety certifications: ANSI/AAMI ES 60601-1 & IEC/EN 60601-1
2xMOPP
Extremely low leakage current <100µA
Suitable for BF rated applications
Low no load power consumption <0.1 Watts
Peak power
Class II (No FG)
Protections: short circuit / over load / over voltage / over temperature
MEAN WELL 3 year warranty
