NSP-100-27
27Vdc, 3.7A, Enclosed Power Supply, 27 Volts 3.7 AmpsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~305Vac
Output Voltage:
27Vdc
Output Max Current:
3.7 Amps
Max Power:
100 Watts
Known Country of Origin:
China
Features
AC/DC High Reliable Multi-Industries Enclosed Type Power Supply
AC input range: 85~305Vac
Operating temperature range: -40~+85°C
No load power consumption <0.3~0.5W by R.C.
Medical safety certification: ANSI/AAMI ES60601-1
2xMOPP
BF Rated
200% peak power capability (12~60V models)
Extremely low leakage current: <350μA
Industrial safety certification: UL 62368-1, UL 61010-1
Class B conducted and radiated emissions
Built-in PFC
Built-in constant current limiting circuit
Built-in remote ON/OFF control
Conformal Coating
Protections: overvoltage / overload / short circuit / over temperature
MEAN WELL 5 year warranty
