XDR-480E-36
36Vdc 13.3A, Ultra Slim Industrial DIN Rail Power Supply, 36 Volts 13.3 AmpsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
36Vdc
Output Max Current:
13.3 Amps
Max Power:
478 Watts
Known Country of Origin:
China
Features
Ultra slim industrial DIN rail power supply
AC input range: 85~264Vac
Operating temperature range: -40~+70°C
Industrial safety certification: IEC/EN 62368-1, IEC/EN 61558-1, IEC/EN 61010, UL 61010
SELV
Overvoltage category III
Built-in constant current limiting circuit
Built-in DC OK signal
Built-in PFC
Current sharing up to 4 XDR-480E, 1920W (3+1)
Installed on DIN rail TS35 / 7.5 or 15
Operation up to 5000m altitude
Protections: short circuit / overload / overvoltage / over temperature
MEAN WELL 3 year warranty
