XTR-960-48PI
48V 20A DIN Rail Power Supply, Three Phase AC Input, Push In Terminal, 48 Volts 20AmpsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$332.90
5
$317.12
10
$303.08
20
$294.38
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
320~600Vac Three Phase
Output Voltage:
48Vdc
Output Max Current:
20 Amps
Max Power:
960 Watts
Known Country of Origin:
China
Features
Ultra slim industrial DIN rail power supply
AC input range: 320~600Vac (3-phase input voltage)
Operating temperature range: -40~+85°C
Industrial safety certification: IEC/EN 62368-1, IEC/EN 61558-1, IEC/EN 61010, UL 61010 Listed
SELV
Overvoltage category III
Built-in constant current limiting circuit
Built-in DC OK signal
Current sharing up to 4 XTR-960, 3840W (3+1)
Installed on DIN rail TS35 / 7.5 or 15
Operation up to 5000m altitude
Protections: short circuit / overload / overvoltage / over temperature
MEAN WELL 5 year warranty
