XDR-120 Series 120W DIN Rail Power Supplies

Designed for global industrial installations, the XDR-120 Series supports an ultra-wide 85 to 305 VAC input range with built-in power factor correction and compatibility with 277 VAC systems. As detailed on page 1 of the datasheet, its compact 30 mm width allows high-density DIN rail mounting, making it ideal for crowded control cabinets and automation panels. The fanless design relies on free-air convection cooling and supports a wide operating temperature range from minus 40 to plus 85 degrees Celsius, ensuring reliable operation in demanding environments.

The XDR-120 Series delivers up to 120 W of rated output power with standard voltage options of 12, 24, 36, and 48 VDC. High peak power capability allows up to 200 percent output for short durations, with pulse current capacity reaching 600 percent to handle motor starts and transient loads. Additional system-level features include remote on and off control, a DC OK relay contact for monitoring, built-in ORing FET for redundancy protection, ultra-low inrush current, and conformal coating for moisture and dust resistance. Certified to IEC, UL, and EN safety standards across industrial, ITE, marine, and hazardous location environments, the XDR-120 Series provides long-term reliability backed by a five-year warranty.
