THM 3-0513WI
15Vdc 0.2A, Medical DC-DC Converter DIP-24 Package 2xMOPPManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
4.5~9Vdc
Output Voltage:
15Vdc
Output Max Current:
0.2 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
TRACO Power THM 3-0513WI medical DIP-24 package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+90°C without derating
Safety approvals: ANSI/AAMI ES 60601-1 & IEC/EN 60601-1 3rd edition
2xMOPP (means of patient protection)
High efficiency
Low leakage current 2µA
I/O isolation 5000 VACrms rated for 250 VACrms working voltage
Input filter to meet EN 55022 class A
Protections: short circuit / over voltage
TRACO Power 5 year warranty
