RDDW40G-15
DC/DC Converter 2x1 Package 2:1 Input, dual outputManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$39.07
10
$38.55
25
$38.05
50
$37.56
100
$36.63
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
1.333 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-1.333 Amps
Max Power:
40 Watts
Features
Ultra-Wide 4:1 input range
Operating temperature range: -40~+90°C
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
I/O isolation: 1600Vdc (F/G models), 3000Vdc (H models)
Dual output
No minimum load required
Fully regulated output
Remote On/Off
Protections: short circuit / overload / overvoltage / over temperature / input under voltage
MEAN WELL 3 year warranty
RDDW40G-15
DC/DC Converter 2x1 Package 2:1 Input, dual outputManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
1.333 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-1.333 Amps
Max Power:
40 Watts
Features
Ultra-Wide 4:1 input range
Operating temperature range: -40~+90°C
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
I/O isolation: 1600Vdc (F/G models), 3000Vdc (H models)
Dual output
No minimum load required
Fully regulated output
Remote On/Off
Protections: short circuit / overload / overvoltage / over temperature / input under voltage
MEAN WELL 3 year warranty
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$39.07
10
$38.55
25
$38.05
50
$37.56
100
$36.63
REQUEST a QUOTE for higher qty discounts
